APG Clamping Machines factory
1.high quality clamping mould
2.Supply APG moulds
3.Experienced engineers
4.Long life service
apg machine frame | 1 set |
electric power pack | 1 set |
hydraulic power pack | 1 set |
mixing frame | 1 set |
mixing pots | 2 sets |
Main Technical Parameters
VOL-100L | ||||
Strirring power | Strirring Speed | Vacuum pump power | Worm gear screw jack | Vacuum degree |
3 (kW) | 21-118 (m/min) | 1.1KW,2800r/min | 0.37 (kW) | 1.5 (mbar) |
Dimension of mixer device | Weight of mixing device | Pot capacity (L) | Machine dimension | Machine weight |
1900X850X1885 (mm) | 680 (KG) | 100L | 910X760X1565(mm) | 455(KG) |
Products
1:Good product quality,fine surface finish of products without bubbles.
2:High efficiency and high automation,only need 1/2 workers operate APG machine,efficiency greatly raised but the intensity of labor is decreased.
3:Chemical resistance,electrical insulation,strength resistance greatly improved.
