Lift Check Valve
Product Quick Detail
- FOB Price
- USD $100.00 / Piece
- Place Of Origin
- CHINA
- Minimum Order
- 1
- Packaging
- International STD seaworthy packing, Plywood Crates
- Delivery
- 15 Days
Specifications
Lift Check Valve
The disc of lift check valve is located on the valve seat sealing surface. And the disc can be free to move up and down, other parts is like a globe valve. When the fluid passes, the disc is lift from the seat sealing surface. When the fluid back flow, the disc falls back onto the seat and cut off the flow. Depending on the condition of using, the disc can be made of full metal construction, or be in rubber or rubber ring on the disc holder.
Specification:
l Size:1/2”~12”
l Pressure Rating: Class150~2500LB
l Main Materials:WCB, WC6, WCC, LCB, CF8, CF8M, CF3, CF3M, 4A, LF2, F304, F316 etc.
l Design and Manufacture: BS 1868, ANSI B16.34
l Face-to-Face:ASME B16.10, DIN3202
l Pressure-temperature Ratings: ASME B16.34
l Ends Connection: Flange,Butt Welding
l Inspection & Testing: API 598, EN12266
Feature:
l Bolted Bonnet - BB
l Lift or Piston Type
l Horizontal or Vertical Service
Non-penetrate Disc Shaft
