Flattened Expanded AISI304 and AISI316 Stainless Steel Stretched Sheet Decorative Mesh

Expanded Stainless Steel Mesh has many advantages over expanded steel as it offers much better corrosion resistance and longer service life. SS expanded sheet and foils are widely used as battery netting, filtration sheet and decorative mesh uses. SS304 and 316 Expanded Meshes are new decorative mesh favored in modern architectural

SS 304 and 316 Series Expanded Plates are supplied with a variety of openings:

1, Standard Rhombic Shaped / Diamond Shaped
2, Heavy Type (Tortoise-shaped)
3, Flattended Type
4, Micron / Micro Opening
5, Special Types

304 Stainless Steel Expaned Mesh Netting:

Stainless Steel 316 Expanded Metal Mesh

SS 316,SS 304,SS Stainless Steel Flattened Expanded Metal:

SWD: 2.5mm-50mm Short Way of the Diamond, the distance from the middle of the bond on one side to the middle of the bond on the opposite side.
LWD: 3mm-100mm(Long Way of the Diamond) is the distance across the largest dimension of the diamond measured halfway between the diamonds.
Width: 0.5m-2.7m, Length:1m-3.6m.
Thickness(gauge): Up to 8mm, Original thickness of metal before expanding.
Strand Width: 0.3mm to 8mm, Amount of metal between diamonds to produce one strand.
SWD, LWD Direction: Parallel to Length or Parallel to Width

Stainless Steel Type 304 Flattened Expanded Metal
