PCB Enclosure Assembly

HX Technology also offers PCB Finish Product Assembly and circuit board enclosure, including assembly with the outer shell and with a wire connector.

With twocustom circuit board

PCBenclosure Design

·Ensure MCAD and ECAD tools use the same data format.

·Select the right component package for thePCB enclosure.

·Ensure that thePCBboxesfits the board size.

·Ensure board cutouts are accurately aligned with component placement.

·Understand the environmental hazards of the installation.

·Consider the impact on signal transmission.

·Select PCB enclosure materials that meet thermal requirements.

·Consider equipment tolerances.

PCB Enclosure Design Guidelines

What is a PCB Enclosure

PCB enclosure is equipment to store and protect printed circuit boards, which can offer a PCB cover. In order to protect the PCB from environmental factors, adding possible consideration of electromagnetic compatibility (EMC), it is almost certain that the PCB will be placed in some form of enclosure. Inevitably, the PCB enclosure will interfere with the free flow of air around the PCB and therefore also have an impact on the thermal performance of the system.

What is a PCB Enclosure

Safety Distance Between PCB and PCB Enclosure

The production and processing of PCBA for the board and the PCB enclosure will generally have safety distance requirements. This distance can ensure that our PCBA board will not be damaged in some harsh environment.

The safety distance between the PCBA board and mounting PCB in the enclosure includes electrical clearance (space distance), creepage distance (distance along the surface), and insulation penetration distance.

HX will custom PCB enclosure with a safety distance for your use!
