DSHS-1B Intelligent Engineering Logging System

Main Applications and Features:

· Hydrological Engineering Digital Integrated Logging, Coal Field Digital Integrated Logging

· Other Minerals Digital Integrated Logging, Solid Metal Ore Digital Integrated Logging

· External Laptop (Desktop PC), Indoor simulation logging, repeatability observation of instruments and probes

· For upward logging, also for downward logging

· Receive digital signal, analog signal

· 8 taps of power supply current, Optional

· Automatic sampling as per depth interval, sampling interval arbitrarily

· Membrane panel, attractive and durable

Technical Specifications:

· 12bit A/D Conversion, Program-Controlled Magnification K=0.5~128

· Counting Channel: f≤500KHz

· Digital Signal Transmission Frequency: 9600bit/s

· Power Supply Cycle: 400ms

· Current: 2mA~500 mA Optional

· Signal Input Range: ≤±10V

· Continuous Working Time: ≤24 hr

· Power Consumption: <200W

· Volume: 420×260×210mm,

· Weight: <7Kg

· Working Temperature Range: -10℃~ +50℃

· Working Power Supply: AC220V±10% 50Hz ±5%

· Logging Speed: 0~30 m/min Adjustable (as per sampling interval)

Logging Working Software System:

· 12bit A/D Conversion, Program-Controlled Magnification

· Operation Environment: Windows98/2000/XP

· Sampling Interval: Arbitrary (1~1000cm)
Setting (1cm, 2cm, ...1000cm)

· Maximum depth of one-time acquisition: 3000m (0.1m sampling interval)

· Depth automatic alignment of multi-parameters

· Superposition of multi-parameters up to 10

· Curve movement, anomaly removal, smoothing, inverted order, , segmentation, calculation, etc.

· Interpretation of profile input, automatic generation of rock stratum name, thickness and baseplate depth

· Curve amplification and compression

· 5 types of curve depth rauction in color or black-and-white effects

· Output graph maximum width: 415mm, length: 2310mm
