DSHH-3 Winch Controller
Product Quick Detail
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Main Function
· Adopt advanced frequency conversion technology to control the winch
· Automatic addition and subtraction to calculate the depth, with depth error automatic compensation.Automatic constant speed and manual speed control, automatic overload protection
· Use of commercial power or AC power generator
· Self-locking function while winch ascending and descending
· Steady in velocity without jitter in full speed range
Technical Specifications
· Speed Range: 1~29.9 m/min
· Depth Error: ≤0.4‰
· Depth Range: 0~9999.99 m
· Power Supply: AC220V±10% 50Hz ±5%
· Continuous Working Time: ≤24 hr
· Depth Pulse Equivalent: 0.25mm/pulse
· Working Temperature: -10℃~ +70℃
· Volume: 305×200×220mm,
· Weight: ＜3kg
· Power Consumption: ＜1.5kW
Constant Speed Range: 0.5~20m/min, Error: ±10%, ±1 digit
