DSH Solidifying Point Constant Temperature Water Bath

A:Product Introduction:

DSH Solidifying Point Constant Temperature Water Bath is designed according the requirements for constant temperature water bath stipulated in the National Standard GB/T510 “Test Methods for Solidifying Point of Petroleum Products”.

DSH Solidifying Point Constant Temperature Water Bath is suitable for use in sample treatment in the range of room temperature to 60 ℃.

B:Technical characteristics:

1. Table structure, newly designed, and it is convenient to be operated.

2. It adopts a digital temperature controller, so it is convenient to set temperature with high temperature controlling accuracy.

3. You can put 7 pieces of solidifying point test tubes and 2 pieces of cold filter plugging point test tubes in the bath, so it can keep temperature of 9 pieces of samples constant at a time.

4. It uses a two layers cylinder, and electric stirrer, so it can keep temperature stable at controlling temperature.

C:Technical parameters:

1. Constant temperature bath:

(1) Cubage: 20 L;

(2) Types: two layers cylinder;

2. Working environment:

(1) Ambient temperature: -10℃～35℃;

(2) Relative humidity: ＜85％;

3. Stirring motor:

(1) Power: 6 W;

(2) Speed: 1200 RPM;

4. Temperature controlling accuracy: ±0.1℃;

5. Heating power: two grades, 1000W and 650 W;

6. Power supply: AC 220V±10%, 50Hz±5%;

7. Total power consumption: not more than 1800 W;

8. Measurement range: room temperature ～100℃;

9. Temperature sensor: Industrial platinum; scale number is Pt100
