Digital Folder&Slitter

Place Of Origin: Zhejiang, China

Minimum Order: 1

Packaging: wooden packing or naked

Delivery: 2 months

This Digital Folder&slitter folder is the high&new technology product developed by our company and Hayes company from New Zealand. It is integrated with electromechanical and hydraulic pressure, using the CNC digital control system to control the back-stop device, upper&lower clamp, folding equipment and so on, which can help to fix, clamp and fold the sheet.

One machine can not only produce one size, it depends on the machine designing. Our digital folder is under CNC control, and can automatically perform various operations such as plate locating, clamping, folding, and slitting. This folding machine is a high-tech product that integrates advanced mechanical, electrical, and hydraulic technologies. It is suitable for use in steel constructions, and also can be used for plate metal folding operations in other industries.

Parameters Of Digital Folder&Slitter

Item Parameters

Model JZW650 JZW800 JZW1000 JZW800D

Max.folding length 6500 8000 10000 8000

Throat depth 800

Max.folding thickness Normal steel 1.5 3 ≤250MPa

Soft aluminum 2 4

Stainless steel 1 2

Max.slitting thickness Normal steel 1.5 3 ≤250MPa

Soft aluminum 2 4

Stainless steel 1 2

Max.folding angle 125

Slitting speed 40

Hydraulic pressure 15

Total hydraulic power 11 18.5

Total power 11.5 19

Total weight 4500 5400 6500 13000

With 53 years' experience, Jinggong is specialized in manufacturing high-quality slitter folder, Want to know the types of auxiliary equipment or buy continuous sandwich panel line, contact us now.
