Aluminium Unequal Channel

Place Of Origin
Shenzhen, Guangdong Province, China
Minimum Order
20
Packaging
Protective Film insdie, Shrink Film or Kraft Paper outsdie
Delivery
25 days

Aluminium Channel for Sale

Aluminium unequal channel are "U-shape" extruded profiles with equal lengths of legs but unequal lengths of the bottom.

In our aluminium channel factory, we offer a wide range of aluminium unequal channels with a variety of alloys, sizes and finishes. Moreover, similar to all the other aluminium extrusion sections produced by Otalum, our unequal channel can also be cut to different sizes if the existing products cannot meet your requirements.

Precise cutting to length and processing services are available with the fastest lead time.

Features of Aluminium Unequal Channel

Alloy Standard Surface Treatment Further Process Certificate
6005 T5/T6, 6060 T5/T6, 6061 T4/T6, 6063 T5/T6, 6463 T5/T6, 6082 T5/T6, etc. GB 5237-2008, JISH, AAMA, GB, BS, En Mill finish, Powder Coating, Anodizing, Wooden grain, Electrophoresis, PVDF Painting, Sanding blasting, Polishing, etc. Drilling, Bending, Welding, Precise cutting, Punching, Fabrication of finished products, etc. CE, DNV, TUV, ISO9001

Specifications of Aluminium Unequal Channel

B=length, mm

H=height, mm

T=thickness, mm

Weight(kg/m)

Item B H T Weight(kg/m)
CH7X12X1.0 7 12 1 0.076
BK84 7.97 11.7 1 0.076
ZY67448 8 10 1.4 0.095
CH7X10X0.8 10 7 0.8 0.049
ARC069 10 20 1 0.13
ZY66165 11.8 14 0.9 0.092
7014H 12 14 0.95 0.105
AZ821 12.7 19.05 3.18 0.381
CH14X35X1.5 14 35 1.5 0.329
ZY-236-CHB0161 15 5 1.3 0.078
CH15X8X1.5 15 8 2 0.13
CH15X10X1.0 15 10 1 0.089
ZYW0046 15.5 6 1 0.06
CH16X6.5X1.6 16 6.5 1.6 0.112
2637 16 28 1.5 0.281
ZY2666 17 18.5 1.5 0.208
ZYP50307-20 17 30 2 0.399
6044 17.6 50 4 1.183
AI-CH1920T12 19 20 1.2 0.184
AZ823 19.05 9.53 3.18 0.273
ZY-246-001 19.5 17 2 0.267
ZY-HK032 20 10 1 0.104
CH20X12X8 20 12 0.8 0.093
ZY-236-012 20 12 1.45 0.162
CH201616 20 16 1.6 0.211
ZYH0070 20 16 3 0.373
ZY-S11-054 20 17 2 0.273
CF90100 20 18 2.5 0.346
ZY14033 20 25 2.5 0.432
ZYW0117 20 33 2.5 0.545
CH20X40X2.0 20 40 2 0.518
ZY-025-085 21 55 1.8 0.625
U21.06X13.5X1.4 21.06 13.5 1.4 0.17
AI-CH2220T12 22 20 1.2 0.194
6043 22.8 50 4 1.239
CRL058 24.73 38.1 2.84 0.729
DT3220 24.8 39 3 0.792
CH3214 25 5 0.9 0.082
CH7X25X0.8 25 7 0.8 0.082
CH2512T09 25 12 0.9 0.113
AI-N733 25 20 1.5 0.254
25 40 3 0.802
TC476 25.4 12.7 3 0.362
AABE-025 26 65 2.8 1.137
CH27X15X0.8 27 15 0.8 0.119
6042 27.9 50 4 1.293
SS2-8271 28 23 3 0.551
CH28.5X35X2.5 28.5 35 2.5 0.702
ZY-246-003 29 22 2 0.373
CF-US-03 29.3 20.7 1.6 0.292
AV1460R 30.25 32.25 4.25 1.002
CH31X16X1.8 31 16 1.8 0.292
AZ824 31.75 12.7 3.18 0.437
TC083 31.75 19.05 3.18 0.545
CE006 31.75 50.8 3.18 1.103
CH3225 32 25 3 0.616
ZY-S11-052 32 30 3.03 0.713
CH32X40X3 32 40 3 0.868
FLEX24 33.9 26 1.8 0.4
CH34X25X2 34 25 2 0.432
ZY-S11-071 35 20 4 0.732
AM2250 35 25 1.5 0.332
ZYW0224 35.5 21.3 1.3 0.264
ZYBY077 37 16 1.5 0.267
CH378525 37.85 25 1.4 0.308
ZY83-15 38 13 1.25 0.208
AQ1134 38 25 1.8 0.415
TC299 38.1 12.7 3.18 0.492
70057KMB 38.1 19.05 3.18 0.606
AF016 38.1 25.4 2.54 0.575
TC085 38.1 25.4 3.18 0.707
CH40X10X1.6 40 10 1.6 0.246
CF-C025 40 20 1.6 0.332
CH402030 40 20 3 0.599
AV1560S 40 25 3 0.68
ZY-S01-934 40 50 5 1.775
AQ1133 42 25 1.8 0.434
ZY66811 42 25 2 0.475
AZ826 44.45 19.05 3.18 0.653
AZ827 44.45 25.4 3.18 0.764
ZYH0193 45 8 0.8 0.132
ZY-582-010 45 35 1.4 0.429
CH45.6X20X3.0 45.6 20 3 0.652
ZYW0110 46 12 1.2 0.218
CH46.8X20X3.0 46.8 20 3 0.661
ZY-236-013 50 13 1.45 0.286
CH5025 50 25 3 0.761
ZY66739 50 27 2.4 0.65
AI-CH25508 50.2 25 1.3 0.378
TC300 50.8 12.7 3.18 0.6
TC228 50.8 19.05 3 0.672
OS-CH004 50.8 25.4 2.29 0.599
OS-CH002 50.8 25.4 3.18 0.818
OS-CH001 50.8 38.1 3.18 1.037
CH088 53.2 25 1.2 0.326
70016KMB 53.34 38.1 1.14 0.402
CF-AUSTPA-1 54 20 1.5 0.369
CH54X30X15 54 30 1.5 0.451
CH55X25X2.0 55 25 2 0.551
ZYPM90A24 59.7 35 2.85 0.964
AM9164 60 32 3 0.956
ZYW0244 60 55 1.5 0.675
ZY66749 61 32.5 1 0.339
CH64X58X6 64 58 6 2.722
CH65X20X1.4 65 20 1.4 0.39
ZYW0082 67 40 3 1.142
CH68.5X25X3 68.5 25 3 0.923
ZY-S03-103 76 13 1 0.273
AZ829 76.2 12.7 3.18 0.818
CH76.2X20X1.6 76.2 20 1.6 0.494
OS-CH006 76.2 25.4 3.18 1.037
AABE-019 76.2 50.8 6.35 2.83
70045KMB 79.38 38.1 1.4 0.581
AM9165 80 25 3 1.004
ZYPED-07 80 45 4 1.75
CH78X30X15 81 30 1.5 0.573
CH8212T11 82 12 1.1 0.308
TC502 82.55 50.8 3 1.442
ZY83-14 83 20 1.25 0.408
9012 87 12 1 0.3
MF2090A11-1.0 87 14 1 0.305
CRL178 88.52 95.25 9.53 6.685
AV1296R 99.85 40 3 1.425
CH100X12X1.5 100 12 1.5 0.489
CH10025T30 100 25 3 1.116
CH1005030 100 50 3 1.577
ZY-001-062 100 50 6 3.046
TC427 101.6 25.4 3.18 1.253
ZYBY089 110 47 3 1.622
ZY-248-001 180 60 3.5 2.77
ZY-275-001 250 160 18 25.944
