Characteristics and advantages of NCM Battery
ncm lithium ion battery
High Energy Density,High Consistency
• The specific energy density of ncm cells reaches 230wh/kg.
• The volumetric energy density of NCM power lithium-ion battery cells reaches 570wh/kg.
• Industry leader in terms of battery energy density.
• High static initial voltage consistency, matching capacity 1%, voltage 2mV, internal resistance 2mΩ.
• Dynamic voltage difference is consistent. The charge-discharge cut-off voltage is highly consistent.
• High consistency on attenuation trend. After a long cycle, the parameters are highly consistent.
Ncm Battery
Long Cycle Life
• The cycle life of the NCM lithium 5.5Ah battery cell is more than 1000 times.
• The cycle life of the NCM lithium 5.0Ah battery cell is more than 1500 times.
• Calendar life over 10 years.
Ncm Cell
High Security of NCM Lithium Battery
• NO explosions, NO fires, and NO liquid leakage accidents over 200 million shipped cells.
• In-depth research on the basic principles of lithium ncm thermal runaway, high-safety seperator selection, and automatically cut off the current under high temperature conditions.
• High safety structure design, precise pressure relief device.
• During the manufacturing process of lithium ion lithium ion ncm, burrs and magnetic metal impurities are strictly controlled.
Product model of battery ncm
INR 26650 5000mah NCM Cell / ncm battery cell
NCM Battery INR26650-5000mAh
Model NO.INR26650-5000mAh
Capacity: ≥ 5000mAh
Impendance: ≤ 20mΩ
Voltage: 3.6V
Diameter: 26.3 ± 0.2mm
Height: 65.3 ± 0.3mm
NCM Cell INR26650-5500mAh
NCM Battery INR26650-5500mAh
Model NO.INR26650-5500mAh
Capacity: ≥ 5500mah
Impendance: ≤20mΩ
Voltage: 3.6V
Diameter: 26.3 ± 0.2mm
Height: 65.3 ± 0.3mm
Product model table
Model NO. Nominal Voltage Rated Capacity Internal Resistance Discharge Rate Dimensions Weight
Diameter Height
INR26650-5000mAh 3.6V 5000mAh ≤20mΩ 2C 26.3±0.2mm 65.3±0.3mm 95g
INR26650-5500mAh 3.6V 5500mAh ≤20mΩ 2C 26.3±0.2mm 65.3±0.3mm 94g
NCM battery are suitable for lead-acid replacement, photovoltaic energy storage, household energy storage, portable power supplies, electric bicycles, golf carts, electric sightseeing cars and
other occasions.
PLB Battery is a professional Lithium Iron Phosphate Battery manufacturer, we provide power long battery, industrial batteries for sale, china lithium battery and etc. If you want to know what is
ncm battery or more, please contact us.
