Characteristics and advantages of PV ESS Battery
Pv Ess
Super Long Life
• The battery cell parameters are consistent, and the BMS intelligent balance management system further improves the efficiency of battery use.
• The calendar life is more than 8 years.
• The cycle life is more than 1500 times, low-cost investment and long-term profit.
Ess Pv
Safe And Reliable
• The internal system has a balanced current management model, a thermal management analysis model, and an anti-vibration and explosion-proof model with stable performance.
• The product has passed modal, vibration, impact, extrusion and other verification tests to ensure a high degree of safety.
Solar Pv and Battery Storage
Strong Environmental Adaptability
• Based on the application scenario, special protection design is adopted, which is waterproof and moisture-proof and can be adapted to avoid various harsh environments outdoors.
• The use of high-end fireproof materials, strong, light, easy to process, not rusty, can effectively avoid vibration, falling, and anti-violent dismantling.
Product model of PV ESS Battery
51.2V 150Ah LFP 2 Residential Energy Storage Systems & Battery
51.2V 150Ah LFP 2 Residential ESS Battery
Model NO.51.2V 150Ah LFP 2
Specification
Nominal Capacity: 150Ah
Operating Voltage: 40~58.4V
Charging current: ≤75A
Discharging current: ≤150A
Temperature: -20~60℃
Dimension: 480*650*180mm(±3mm)
Weight: 85Kg
Packaging: SPCC Iron case
Protection: PCM (Customized available)
Home Battery Storage System, 51.2V 150Ah LFP 1Residential ESS Battery
51.2V 150Ah LFP 1 Residential ESS Battery
Model NO.51.2V 150Ah LFP 1
Specification
Nominal Capacity: 150Ah
Operating Voltage: 40~58.4V
Charging current: ≤75A
Discharging current: ≤150A
Temperature: -20~60℃
Dimension: 480*650*220mm(±3mm)
Weight: 82Kg
Packaging: Aluminum case
Protection: BMS (Customized available)
12.8V 26.4Ah LFP Battery
12.8V 26.4Ah LFP Small PV Energy Storage Battery
Model NO.12.8V 26.4Ah LFP
Specification
Nominal Capacity: 26.4Ah
Operating Voltage: 10~14.6VDC
Charging current: ≤30A
Discharging current: ≤30A
Temperature: -20~60℃
Dimension: 139*145*125mm(±3mm)
Weight: 4.1Kg
Packaging: SGCC iron case seal by laser welding.
Protection: BMS (Customized available)
12.8V 13.2Ah LFP Small Lithium Ion Battery For Solar Storage
12.8V 13.2Ah LFP Small PV Energy Storage Battery
Model NO.12.8V 13.2Ah LFP
Specification
Nominal Capacity: 13.2Ah
Operating Voltage: 8.4~14.6V
Charging current: ≤10A
Discharging current: ≤10A
Temperature: -20~60℃
Dimension: 120*110*69(±3mm)
Weight: 1.55Kg
Packaging: Wrap by PVC
Protection: PCM (Customized available)
LFP Solar Street Light Battery
12.8V 33Ah LFP Solar Streetlight Battery
Model NO.12.8V 33Ah LFP
Specification
Nominal Capacity: 33Ah
Operating Voltage: 8.4~14.6VDC
Charging current: ≤15A
Discharging current: ≤15A
Temperature: -20~60℃
Dimension: 270*163*96(±3mm)
Weight: 2.5Kg
Packaging: Plastic waterproof case/IP67
Protection: PCM (Customized available)
12.8V 23.1Ah LFP Solar Street Light Lithium Battery
12.8V 23.1Ah LFP Solar Streetlight Battery
Model NO.12.8V 23.1Ah LFP
Specification
Nominal Capacity: 23.1Ah
Operating Voltage: 8.4~14.6V
Charging current: ≤10A
Discharging current: ≤10A
Temperature: -20~60℃
Dimension: 267.4*197.4*29(±5mm)
Weight: 2.8Kg
Packaging: Wrap by PVC
Protection: PCM (Customized available)
Product model table
Model NO. Rated Capacity Operation Voltage Charging Current Max Discharge Current Max Energy Dimension(mm) Weight
Length Width Height
12.8V 26.4Ah LFP 26.4Ah 12.8V 30A 30A 338Wh 139±3mm 145±3mm 125±3mm 4.1Kg
12.8V 13.2Ah LFP 13.2Ah 12.8V 10A 10A 169Wh 120±3mm 110±3mm 69±3mm 1.55Kg
12.8V 33Ah LFP 33Ah 12.8V 15A 15A 422.4Wh 270±3mm 163±3mm 96±3mm 2.5Kg
12.8V 23.1Ah LFP 23.1Ah 12.8V 10A 10A 295.7Wh 267.4±5mm 197.4±5mm 29±5mm 2.8Kg
51.2V 150Ah LFP 2 150Ah 50.4V 75A 150A 7560Wh 480±3mm 650±3mm 180±3mm 85Kg
51.2V 150Ah LFP 1 150Ah 50.4V 75A 150A 7560Wh 480±3mm 650±3mm 220±3mm 82Kg
1.Application of pv battery storage: Green solar energy is used as the power source that widely used in garden lights,landscape lights, camping lights,lawn lights,traffic warning lights and other
LED fields,with built-in light control and time control systems.
2.Features of pv ess: Simply installation,high light efficiency, the solar pv battery has the characteristics of a wide temperature range,including a controller system,and its own energy-saving
regulation.It has the characteristics of good stability,high safety,and long service life.
3.What is solar pv battery storage system?
The solar pv battery storage system is a system that uses lithium batteries or lead-acid batteries as energy storage carriers to store electrical energy for a certain period of time and supply
electrical energy for a certain period of time, and the provided electrical energy has functions such as smooth transition, peak shaving and valley filling, frequency regulation and voltage
regulation.
4.Benefits of solar storage battery?
Solar energy is the most common green energy source, and it is inexhaustible. PV battery can convert solar energy into electrical energy to meet the daily use of users, which is the best solution
for environmental protection. In addition, the lithium battery has a long cycle life and a high energy density, and it is also the most suitable choice for solar energy storage.
As one of the professional lithium battery companies, we provide power long battery, industrial batteries for sale, plb battery and etc. If you want to know more, please contact us.
