Outer Cylinder Length: 6 - 8.5 m
Production Capacity: 20 - 99 t/h
Application Range: Coal industry, ore beneficiation industry, steel making industry and sand making industry.
Processible Materials: Slag, sand, coal, coal ash, iron powder, minerals, silica sand.
Coal Ash Dryer Introduction:
Fly ash or coal ash dried by coal ash dryer can be used as admixture for cement, mortar and concrete, and can be part of the cement and concrete. Fly ash or coal ash can instead raw materials of cement to produce raw materials of cement clinker, fired brick, aerated concrete, foam concrete, sintered or non-sintered ceramsite hollow brick, etc. According to the moisture requirements of dried materials in different industries, the moisture content of dried materials can be reached 1-0.5%.
Coal Ash Dryer Features:
1. Low outlet temperatures, long service life of dust removal equipment.
2. Use new modular lifting device, so desired final moisture indicator can easily be regulated according to users’ requirements.
3. High automation, easy operation, smooth running.
4. Low investment, quick earnings.
5. The equipment is new energy-saving product, with energy saving of 20% than that of other similar products.
6. Fuel such as coal, oil and gas can be used in fly ash dryer or coal ash dryer.www.china-ftm.com/pros/coal_ash_dryer.html
Product Specification (m) | Processing capacity(t/h) | Motor power-type (kw) | Reducer type | Feeding moisture(%) | Heat value of bunker coal | Discharging moisture (%) |
Φ1.2x10 | 2.5-3 | M160M-6-7.5 | ZQ350Ⅱ-25 | 25±5 | ≥5500 | ≤13 |
Φ1.5x14 | 7-9 | Y180L-6-15 | ZQ400Ⅱ-31.5 | 25±5 | ≥5500 | ≤13 |
Φ1.5x18 | 9.5-12 | Y180L-6-15 | ZQ400Ⅱ-31.5 | 27±5 | ≥5500 | ≤13 |
Φ1.8x14 | 12-15 | Y200L-6-18.5 | ZQ400Ⅱ-31.5 | 25±5 | ≥5500 | ≤13 |
Φ1.8x18 | 14-18 | Y200L1-6-18.5 | ZQ400Ⅱ-31.5 | 27±5 | ≥5500 | ≤13 |
Φ2.0x18 | 18-22 | Y200L2-6-22 | ZQ50Ⅱ-31.5 | 25±5 | ≥5500 | ≤13 |
Φ2.0x20 | 18-23 | Y200L2-6-22 | ZQ50Ⅱ-31.5 | 30±5 | ≥5500 | ≤13 |
Φ2.2x18 | 21-25 | Y200L2-6-22 | ZQ65Ⅱ-31.5 | 27±5 | ≥5500 | ≤13 |
Φ2.2x20 | 22-25 | Y225M-6-30 | ZQ65Ⅱ-31.5 | 30±5 | ≥5500 | ≤13 |
Φ2.4x20 | 25-29 | Y225M-6-30 | ZQ75Ⅱ-31.5 | 27±5 | ≥5500 | ≤13 |
Φ2.4x22 | 26-30 | Y225M-6-30 | ZQ75Ⅱ-31.5 | 30±5 | ≥5500 | ≤13 |
Φ2.6x20 | 28-33 | Y250M-6-37 | ZQ85Ⅱ-31.5 | 25±5 | ≥5500 | ≤13 |
Φ2.6x24 | 29-35 | Y250M-6-37 | ZQ85Ⅱ-31.5 | 30±5 | ≥5500 | ≤13 |
Φ3.0x20 | 45-50 | Y280S-6-45 | ZQ100Ⅱ-31.5 | 25±5 | ≥5500 | ≤13 |
