Disk / Flange Forging Component
Product Quick Detail
- Minimum Order
- 20
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
The basic process used for disk forgings is upsetting, and then chamfering, rounding, and leveling as the subsequent auxiliary processes and finishing processes.
The flange is a part that connects the pipe to the valve or other pipes. It is to continuously beat raw material after cutting, so that to eliminate defects such as segregation and looseness in the
steel ingot. The price and mechanical properties are both higher than that of ordinary cast flanges.
Main Parameters of HS Metal Steel Discs/Forged Flanges For Sale
Forged Disks：Φ70~Φ1200mm
Forged Flanges：Φ70~Φ1200mm
Forged Disk/Flange Common Technical Standards
Round Metal Discs: NB/T47008~47010
Forged Steel Flanges: GB/T3077 EN10083 EN10084 EN10085 JB/T6395
Typical Steel Grades of HS Metal Steel Discs/Forged Flanges For Sale
Forged Discs: #20, #35, 16Mn, 15CrMo, 1.25Cr-0.5Mo, 2.25Cr-1Mo, 2.25Cr-1Mo-0.3V, 12Cr2Mo1V, 21CrMo10, 0-1Cr8Ni9(Ti), 1Cr17Ni2, 304(L), 316L(N), 321, 347, 00Cr19Ni13Mo3, 00Cr22Ni5Mo3N
Forged Flanges: 18CrNiMo7-6, 17CrNiMo6, 20CrNiMo, 20CrNi2Mo, 20CrMnMo, 20CrMnTi, 34CrNiMo6, 30CrNiMo8, 40CrNiMo, 35CrMo, 42CrMo
Forged Discs/Flanges Applications
Like our cylinder forgings products, the forged disks for sale can be used for gears, wheels, etc. for port machinery and marine machinery. Pressure vessel disk forgings for chemical machinery
There are many die steel suppliers in China, but we are one of the best choices for you.
- Country: China (Mainland)
- Business Type:
- Market:
- Founded Year:
- Address:No.1 Dongmeng Rd,Dongmeng Technology Industrial Aggregation Area, Guanshan Village,Nanzha Street, Jiangyin,Jiangsu,China
- Contact:Echo Dai
