ATE Series Wireless Temperature Sensor
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Wireless temperature sensor for cable joint.
Model NAME SPECIFICATIONS PHOTO
ATE100 Temperature Sensor 62.4*32.4*16mm, Φ13.5mm,
-50°C ~+125°C
Accuracy:± 1°C
Lifetime>5 years
470Mhz,
Open space distance:150m
Installation: bolt fixing
ATE100M Temperature Sensor 32.4*32.4*16mm
-50°C ~+125°C
Accuracy:± 1°C
Lifetime>5 years
470Mhz,
Open space distance:150m
Installation:magnetic absorption fixation
ATE200 Temperature Sensor 35*35*17mm,
-50°C ~+125°C
Accuracy:± 1°C
Lifetime>5 years
470Mhz,
Open space distance:150m
Installation: strap binding
ATE400 Temperature Sensor 25.82*20.42*12.8mm
-50°C ~+125°C
Accuracy:± 1°C
CT induction of electricity powered,
starting current>5A
470Mhz,
Open space distance:150m
Installation: Alloy sheet fixed and powered
AHE100 Temperature& Humidity Sensor Temperature range -30℃~+85℃
Humidity 10~100%RH
Temperature accuracy ±1℃
Humidity accuracy ±3%RH
Transmit frequency 5min
Transmission distance space distance 500m
Installation: Din rail
ATC600-C Receiver 90*90*38mm
Power Supply AC/DC 85-265V
1 channel uplink RS485 Modbus protocol
Receive 240 ATE sensors(ATE100/ATE200/ATE400/)
Installation:35mm DIN rail screws fixed
ARTM-Pn Temperature Display Maximum measuring 60 points
Measure all parameters
1 RS485 Modbus
Power supply AC85-265V
ATP007 7 inch touch screen
1 channel uplink RS485 port
1 channel uplink Ethernet port
High temperature warning with buzzer
Power supply DC24V
ARTM-24 1 channel RS485 port (Modbus portocol)
24 channels Pt100/NTC
one channel temperature and humidity measurement
2-way relay alarm output
temperature accuracy ±1℃
Power supply AC/DC 85-265V
If you want to know more kinds of remote temperature measuring device, please visit our website.
