Navigation Mark Light
Product Quick Detail
- Place Of Origin
- Shenzhen
- Packaging
- Customized Carton
- Delivery
- 15 Days
Specifications
XB-HB1LT is a white flashing solar light fixture and can be installed along both sides of inland waterway. The product can send out white omnidirectional steady burning light signal which is slowly varying to mark the direction of inland waterway, boundaries and obstruction. It is an important aid to navigation to keep shipping safely which points out safe and economic waterway for shipping.
Patents:
- Developed product and owns independent intellectual property rights for product
- Optical lens which is solely developed by our company and used at product is patented as invention.
- Patent number is ZL200910109495.0
Features:
- As result of using patented optical lens in product and applying six OSRAM super-high efficiency LED as light source, product obtains:
- Brilliant optical effects
- Very high efficiency of light source conversion
- Evident effect of energy-saving
- Rated power: 0.15W
- As cooling and structural parts of product are made of lightweight aluminum alloy and unique structure of cooling focuses on dealing with conduction, convection and radiation at same time, the product processes:
- Nice effect of cooling
- Lightweight structure
- Small size
- 2.3kg weight
- Easy to transportation and install
- As to driving features of LED lights, the most advanced Li-Battery in the world is used for product, which leads to:
- High capacity and Light weight
- Service life with more than three years
- Greatly reduce transportation cost and maintenance cost of users
- Work continuously more than 12 days during rainy days after full charged
Compliance with standards:
- General Navigation light technical conditions(JT/T761-2009)
- Inland river navigation AIDS(GB5863-93)
Warranty declaration:
- Equipment have three-year quality-guarantee and five-year maintenance-guarantee
- Man-made damage or force majeure voids warranty
