GDGS Automatic Tangent Delta Tester
Product Quick Detail
- Place Of Origin
- China
- Packaging
- Standard wooden case and carton according to customer's requirement
- Delivery
- 15 Working Days
Specifications
Brief Introduction
GDGS Automatic Tangent Delta Tester /Transformer Substation Tangent Delta Tester is applied to meaure the dielectric loss and capacitor value of insulating materials.
GDGS Automatic Tangent Delta Tester /Transformer Substation Tangent Delta Tester is applied to measure the dielectric loss and capacitor value of insulation materials in high voltage power equipment. The non-power frequency voltage source is integrated in the tester to avoid power frequency interference. That make the tester has a good performance in measurement precision.
Main Parameter
| Model | GDGS Automatic Tangent Delta Tester /Transformer Substation Tangent Delta Tester |
| Condition of Use | -5°C~40°C, RH<80% |
| Power Source | AC 110V±10% Without Frequency Limit |
|
High Voltage Output Range |
1KV~10KV, every 1KV |
| Precision | 5% |
| Maximum Current | 140mA |
| Capacity | 1000VA |
|
Self-Excited Power Voltage Range |
AC 0V~30V |
| Frequency | 45Hz /55Hz |
| Maximum Current | 15A |
| Output voltage | AC 0.5KV~10KV |
| Testing voltage setting resolution | 0.5KV |
| Maximum output capacity | 200mA |
| Testing frequency | 45Hz/55Hz |
| Test mode | fully automatic |
| Power supply | AC220V± 50Hz/60Hz%10% |
| Environment temperature | 0-50°C |
| Humidity | ≤85%RH |
| Weight | 40KG |
