Outdoor LCD Display
Product Quick Detail
- Place Of Origin
- China
- Packaging
- wooden box
- Delivery
- 15 Days
Specifications
| Model No. | YT5500P | YT6500L | YT6500L-S |
| LCD Panel Size | 55'' | 65'' | 65'' |
| Panel Brand | LG | AUO | AUO |
| Aspect Ratio | 09:16 | 16:9 | 16:9 |
| Backlight Technology | LED | LED | LED |
| LCD Panel Technology | IPS | MVA | MVA |
|
Display Colours |
16.7M | 1.07M | 1.07M |
| Display Size | 1209.6×680.4mm | 1428.4×803.5mm | 1428.4×803.5mm |
| Resolution | 1920×1080 | 1920×1080 | 1920×1080 |
| Pixel Pitch | 0.630×0.630 mm | 0.744×0.744 mm | 0.744×0.744 mm |
| Brightness | 1500cd/m2 | 1500cd/m2 | 1500cd/m2 |
| Contrast Ratio | 1300:1 | 5000:1 | 5000:01:00 |
| Viewing Angle | 178° | 178° | 178° |
|
Response Time |
8ms | 8ms | 8ms |
| Brightness Control | Automatic control | Automatic control | Automatic control |
| Backlight Life | 50000 Hours | 50000 Hours | 50000 Hours |
| Installation Method | Floor standing | Floor standing | Embeded mounting |
|
Dimension of Overall Unit |
1895*1450*300mm | 2200*1150*250mm | 1870*1200*250mm |
| Material of Housing |
Steel with painting or alumimium with painting (alternative) |
Steel with painting or alumimium with painting (alternative) |
Steel with painting or alumimium with painting (alternative) |
| Exterior Colours | Silver or customized color |
Silver or customized color |
Silver or customized color |
| Protection Rating |
IP55 (Fan cooling) IP65(Air conditioner cooling ) |
IP55 (Fan cooling) IP65(Air conditioner cooling ) |
IP55 (Fan cooling) IP65(Air conditioner cooling ) |
| Weight | 220 kg | 275 kg | 240 kg |
|
Computer Serial Input |
RSR-232 | RSR-232 | RSR-232 |
| Network cable port | RJ45 | RJ45 | RJ45 |
| DVI Input | One DVI input | One DVI input | One DVI input |
| HDMI Input | One HDMI input | One HDMI input | One HDMI input |
| Mains Input | AC100-240V,50/60Hz | AC100-240V,50/60Hz | AC100-240V,50/60Hz |
| Power Consumption | 850W | 1500W | 1400W |
| Standby Power consumption | 30W | 30W | 30W |
| Temperature Control | Intelligent constant temperature control | Intelligent constant temperature control | Intelligent constant temperature control |
| Operating Temperature | -30°C~55°C | -30°C~55°C | -30°C~55°C |
| Storage Temperature | -40°C~75°C | -40°C~75°C | -40°C~75°C |
| Working/Storage Humidity | 10%-90% | 10%-90% | 10%-90% |
| Cooling system | Forced air cooling or Air conditioner (Optional) | Forced air cooling or Air conditioner (Optional) | Forced air cooling or Air conditioner (Optional) |
| Hardware |
Embeded player or PC player(Optional) Touch function(Optional) Camera Monitoring (Optional) 3G networking (Optional) |
Embeded player or PC player(Optional) Touch function(Optional) Camera Monitoring (Optional) 3G networking (Optional) |
Embeded player or PC player(Optional) Touch function(Optional) Camera Monitoring (Optional) 3G networking (Optional) |
| Software |
Content releasing system from the server
Player system Inquiry system(Optional) Local monitorng security system(Optional) Remote network (Optional) |
Content releasing system from the server
Player system Inquiry system(Optional) Local monitorng security system(Optional) Remote network (Optional) |
Content releasing system from the server
Player system Inquiry system(Optional) Local monitorng security system(Optional) Remote network (Optional) |
