VLF AC Hipot Test Set

Place Of Origin
China
Packaging
Standard wooden case and carton
Delivery
15 Days
VLF AC Hipot Test Set

I.Introduction

VLF AC Hipot Test Set combines modern advanced digital variable frequency technology and micro computer control together, therefore, it can realize the

full automatic voltage boost, stepdown, measurement and protection as well as the manual intervention in the process of automatic voltage boost.

The full electronic design ensures the small size and light weight. The big LCD screen ensures the clear and visual

display, and can display the output wave form. The printer outputs test reports.

In addition, VLF AC Hipot Test Set has features as follows:

Data of current, voltage, wave form can be directly sampled at high voltage side, so the data is real and accurate.

Overvoltage protection: If the output exceeds the set limit of voltage, the instrument will shut-down to protect itself, the actuation time is less than 20ms.

Overcurrent protection: it is high-low voltage dual protection in the design, the accurate shut-down protection can be made according to the set value at high voltage side; If the current on low voltage side exceeds the rated

current, VLF will take shut-down protection, the actuation time are both less than 20ms.

A high voltage output protective resistor is provided in the voltage boost body in the design and this eliminates the need of

additional protective resistor connected outside.

II.Technical parameters

1. Output voltage ratings: See Details of Table 1

2. Output frequency: 0.1Hz, 0.05Hz, 0.02Hz

3. Measurement accuracy: 3%

4. Positive and negative voltage peak errors: ≤ 3%

5. Voltage wave form distortion: ≤ 5%

6. Use condition: indoor and outdoor; temperature: -10°C+40°C

Humidity: ≤ 85%RH

7. Power: AC50Hz, 220V ±5%

8. Power supply fuse tube: See Details of Table 1(Contact me)
