Model: steel grating
Material:high quality low carbon steel , stainless steel
Surface treatment:Hot-dipped galvanizing, polishing or untreated
MOQ:10 pcs or 500kgs
daily ouput:1000square meter or 100tons
FOB Price range:Fob Tianjin xingang USD12-90per sq.m.
USD700-950 per ton
payment terms: T/T, L/C
Delivery time:
Delivery Detail: 10days-20 days after confirmed
1) Bearing Bar (Load Bar) Specifications (mm):
The specification of plain type and serrated type bearing bar is 20 x
3 to 100 x 9;the specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4,
2) Bearing Bar Pitch (center to center):
12.5 to 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended, America standard is available.
3) Cross Bar Pitch (center to center):
from18.5 to 101.6mm etc, also be according to client's requirement and 50, 100mm are recommended, America standard is available.
4) Material:
Low Carbon Steel or Stainless Steel
5) Surface Treatment:
Untreated, Painting or Hot Dipped Galvanizing
If you are interested to get an inquiry for us, please give me following information,
1, Grating type -- It includes bearing bar type (height & thickness), bearing bar pitch, cross bar pitch. For example: G325/30/100P, G255/30/100S
2, Grating size -- That is panel length by width.
Remark: the length refers to bearing bar direction, and it also called panel span
3, Quantity of grating -- measured by pieces or square meters, and measured by weight is also available if the grating size is complex.
4. End finished – band (closed end) or no band (open end), and special band according to your requests.
5. Surface treatment -- Hot-dip galvanizing or no special treatment
If you are not clear about what's type of grating you need, please feel free to tell me what will be the grating used for, maybe I can help make a choice.
