Model: YC-SG08
Material:high quality low carbon steel , stainless steel
Surface treatment:Hot-dipped galvanizing, polishing or untreated
MOQ:10 pcs or 500kgs
daily ouput:1000 square meter or 100 tons
FOB Price range: Fob Tianjin xingang USD12-90 per square meter
USD700-950 per ton
payment terms: T/T, L/C
Delivery time:
Delivery Detail: 10days-20 days after confirmed
1) Bearing Bar (Load Bar) Specifications (mm):
The specification of plain type and serrated type bearing bar is 20 x
3 to 100 x 9;the specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4,
2) Bearing Bar Pitch (center to center):
12.5 to 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended, America standard is available.
3) Cross Bar Pitch (center to center):
from18.5 to 101.6mm etc, also be according to client's requirement and 50, 100mm are recommended, America standard is available.
4) Material:
Low Carbon Steel or Stainless Steel
5) Surface Treatment:
Untreated, Painting or Hot Dipped Galvanizing
The steel grating is an open steel member which is fixed by orthogonally supporting the flat steel and the cross bar at a certain interval and fixed by welding or pressure lock; the cross bar is generally made of twisted square steel,round steel or flat steel. Steel gratings ...
STEEL GRATING PLATE Steel grating plate is generally made of carbon steel, the appearance of hot galvanized, can play a role in preventing oxidation, but also can be made of stainless steel. Steel grid plate with ventilation, lighting, heat, anti-skid, explosion-proof and other ...
