Frame
Scale Carbon
IMP technology / HMX / Tapered HT
PM 160 Disc / BB92
IDS SL DM dropouts for 142x12mm
SDS Shock Damping System
Fork
FOX 32 Float Factory Air / Kashima
FIT4 3-Modes with low speed adj.
15mm QR axle / tapered steerer
Lockout / reb. Adj. / 100mm travel
Remote System
SCOTT RideLoc Remote Technology
3 modes / integ. clamp
Headset
Syncros FL1.5 / Tapered 1.5" - 1 1/8"
Semi integ. OD 50/61mm / ID 44/55mm
Rear Derailleur
Shimano XTR RD-M9000 SGS / DM
Shadow Plus Type / 22 Speed
Front Derailleur
700 Series: Shimano XTR FD-M9025-E
900 Series: Shimano XTR FD-M9025-H / 34.9
Shifters
Shimano XTR SL-M9000-I
Rapidfire Plus / 2 way release
Ispec 2 clamp
Brakes
Shimano XTR M9000 Disc
180/F and 160/Rmm SM-RT99 CL Icetech Rotor
Crankset
Shimano XTR FC-M9000-2
Hollowtech 2 / QF 158
36x26 T
BB-Set
Shimano SM-BB94-41A / shell 41x89.5mm
Handlebar
Syncros FL1.0 Carbon T-Bar
T shape flat / 9° / 720mm
Syncros Pro lock-on grips
Handlebar Stem
Syncros XR1.0
700 Series: -2° / 900 Series: -10°
7050 Carbon wrapped / 31.8mm / 1 1/8"
Seatpost
Syncros FL1.0 Carbon
ECL Ergoptimized Comfort Layup
700 Series: 31.6mm / 900 Series: 34.9mm
Seat
Syncros XR1.5 / Titanium rails
Hub (Front)
Syncros XR1.5 CL / 15mm
made by DT Swiss
Hub (Rear)
Syncros XR1.5 CL / 142x12mm / RWS axle
36T Rachet System / made by DT Swiss
Chain
Shimano CN-M900-11
Cassette
Shimano XTR CS-M9000
11-40 T
Spokes
DT Swiss Aero Comp
Rims
Syncros XR1.5
28H / Tubeless ready
Tires
Schwalbe Rocket Ron EVO / 2.1
127EPI Kevlar Bead
Tubeless Easy / PaceStar compound
Weight
9.3kg/20.5lbs
