Palisade Fencing Post
Product Quick Detail
- FOB Price
- USD $500.00 / Piece
- Place Of Origin
- china
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Palisade Fencing Post for three different installation methods
Palisade post is an integral part of palisade fencing and supports the whole fencing panels. It is used to be hot-rolled RSJ beam with the same height and surface finish with the palisade fencing. As far as the head type, the RSJ beam is often one-pointed. Palisade fence is installed in different methods as the fig 1 to fig 3 in the below.
| Palisade fencing type | Palisade fencing item | Fence height above ground (m) | Post | |
|---|---|---|---|---|
| RSJ beam (mm) | Embedded length (mm) | |||
| General Palisade Fencing | GP15 | 1.50 | 102 × 44 | 525 |
| General Palisade Fencing | GP18 | 1.80 | 102 × 44 | 525 |
| General Palisade Fencing | GP21 | 2.10 | 102 × 44 | 625 |
| General Palisade Fencing | GP24 | 2.40 | 102 × 44 | 725 |
| High Security Palisade Fencing | SP30 | 3.0 | 127 × 76 | 925 |
| High Security Palisade Fencing | SP36 | 3.6 | 127 × 76 | 1125 |
However, for palisade fencing gates, the RHS tube post is often equipped. Similar to RSJ posts, it is also has the same surface finish and height as the fence. Besides, post caps are available to prohibit rain.
RSJ bolt-down galvanised fencing post
RHS palisade fencing gate post
| Fence height (m) | Embedded length (mm) | RHS post sizes for palisade gate leaf widths (mm) | |||||||
| ≤1.5m | 1.5-1.75m | 1.75-2.5m | 2.5-3.5m | 3.5-3.75m | 3.7-4.75m | 4.75-5.5m | 5.5-6.5m | ||
| 1.5 | 525 | 80 × 80 × 5.0 | 100 × 100 × 6.3 | 100 × 100 × 6.3 | 120 × 120 × 6.3 | 150 × 150 × 6.3 | 150 × 150 × 6.3 | 150 × 150 × 6.3 | 200 × 200 × 6.3 |
| 1.8 | 525 | 80 × 80 × 5.0 | 100 × 100 × 6.3 | 100 × 100 × 6.3 | 120 × 120 × 6.3 | 150 × 150 × 6.3 | 150 × 150 × 6.3 | 150 × 150 × 6.3 | 200 × 200 × 6.3 |
| 2.1 | 625 | 80 × 80 × 5.0 | 100 × 100 × 6.3 | 120 × 120 × 6.3 | 120 × 120 × 6.3 | 150 × 150 × 6.3 | 200 × 200 × 6.3 | 200 × 200 × 6.3 | 200 × 200 × 10 |
| 2.4 | 725 | 80 × 80 × 5.0 | 100 × 100 × 6.3 | 120 × 120 × 6.3 | 120 × 120 × 6.3 | 150 × 150 × 6.3 | 200 × 200 × 6.3 | 200 × 200 × 6.3 | 200 × 200 × 10 |
| 3.0 | 925 | 100 × 100 × 6.3 | 100 × 100 × 6.3 | 120 × 120 × 6.3 | 150 × 150 × 8.0 | 200 × 200 × 6.3 | 200 × 200 × 6.3 | 200 × 200 × 6.3 | 250 × 250 × 8 |
| 3.6 | 1125 | 100 × 100 × 6.3 | 100 × 100 × 6.3 | 120 × 120 × 6.3 | 150 × 150 × 8.0 | 200 × 200 × 6.3 | 200 × 200 × 6.3 | 200 × 200 × 6.3 | 250 × 250 × 8 |
Three fixing methods for steel palisade fencing:
Fig-1. Set in concrete foundation.
Fig-2. Bolted down to concrete by base plate.
Fig-3. Cranked post designed for the palisade fence installed on the wall.
Fig-1 Palisade fencing installed in a concrete foundation
Fig-2 Palisade fencing installed in the wall with bolt-down post and base plate.
Fig-3 Palisade fencing installed on the wall with cranked RSJ post.
