UA3200E SLIDING TABLE PANEL SAW

Place Of Origin
China (Mainland)
Minimum Order
1
Packaging
8 sets/20GP
Delivery
20 Days
UA3200E SLIDING TABLE PANEL SAW



DETAILS SHOWS


FEATURES

1) 3200*415mm Sliding table, 45-90 degree cutting.

2) 5.5kw/1.1kw motor.

3) Electrical main saw blades up and down, degree adjustment by electrical.

4) ISO, CIQ Quality control.

5)Colors, models and functions , we could process and design according to your requirements.

TECHNICAL DATA

Dimension of sliding table 3200*415mm
Gross cut capacity 3200mm
Width of cut between saw blade and ripe fence 1250mm
Saw blade 300mm (250-350)
Height of cut 300mm 70mm
Speed of main saw blade 6000r.p.m
Tiling saw blade 45 Degree
Main motor 5.5kw
Scoring saw blade diameter 120mm
Speed of scoring saw blade diameter 8000r/min
Scoring motor 1.1kw
Weight 850kg
Overall dimensions 3200*3100*985mm
Loading 20GP 8SETS

PACKAGE

1.Thick PE foam inner, plastic film outside, in case of damage during transportation
2.Seaworthy wooden case as the general export package should be additional charged

DELIVERY TIME

20days after confirming order and received the deposit,detail delivery date should be decided according to
production season and order quantity.
