51.2V 33Ah LFP AGV Battery

AGV Battery

Part number of agv battery:

51.2V 33Ah LFP Battery

Features of battery agv:

• Power Lithuim-ion battery Pack

• Use in Intelligent Patrol Robot, AGV, Service robot ect

• Protection IC,stable working

• Long running life, High stability, Low maintenance costs

• Easy to carry by handle design

• IP45 Rating

• High capacity density to have a range of long miles on a charge

• Low-power consumption,Long standby time

• Portection with Overcharge/Overdischarge/Overcurrent/Short circuit/temperature protection to ensure safety while using

• RoHS eco-friendly design

• Pack approved by IEC62619/UN38.3 certification

• PCM & cell double protection to ensure the battery safety

1.Specification of agv battery：

Item Parameter

Model 51.2V 33Ah LFP Battery

AGV battery Capacity 33Ah

Minimum Capacity (0.5C，A) 32Ah

Rated Voltage 51.2V

Max Charge Voltage 58V

Cut-Off Voltage 40V

Standard Charge And Discharge Current 15A

Max Continuous Charge Current 30A

Item Parameter

Max Continuous Discharge Current 30A

Weight (Approx. Includes Case) ～20Kg

Impedance (Max, At 1000Hz.) ≤50mΩ

Charge Method (CC) 6A（58.4VCut Off）

Charge Method (CV) 58.8V（0.6ACut Off）

Operating Temperature Charging 0℃～45℃

Operating Temperature Discharge -20℃～60℃

Operating Temperature Storage -20℃～45℃

2.Bock diagram of agv battery：

Highly intelligent battery pack management, safe, reliable and stable performance protection design, impedance tracking and ampere-hour estimation, high-precision SOC, charge balance management, can exchange battery data information with PLC through dedicated communication, remote monitoring, online debugging, Special APP monitors battery status for easy maintenance.

3.Outline Drawing of agv battery：

The SPCC shell solution is full of industrial sense, with double handle design, convenient for installation and transportation, separate input and output, and one charge and one discharge are safer. Anderson SB50 interface, suitable for most AGV; external communication interface, better interaction with outsiders, actual product size: 320mm*250mm*170mm.

4.AGV Battery Capacity：

Using PLB high-quality lithium iron phosphate battery, made by resistance welding technology, strong external interface adaptability, high capacity, 33Ah, support 1C continuous charge and discharge, strong power, suitable for most AGV and other equipment on the market. It is the best choice for the power of these devices.

PLB Battery is a professional Lithium Batteries Supplier, we provide china lithium battery, plb battery and etc. If you want to know lithium battery cell price, please contact us.
