Lithium ion UPS Battery Backup
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Characteristics and advantages of Lithium ion UPS Battery Backup
Usb C Backup Battery
High Input And Output
• Using high-quality lithium iron battery backup as raw materials, select batteries with the same capacity, voltage, and internal resistance to form a battery pack.
• The battery pack can support high-rate charging and high-rate discharge, which can meet most emergency situations.
• Adapt to ambient temperature -20℃~65℃ charge and discharge.
Usb Power Backup
Safe And Reliable
• All-round battery intelligent management, multiple safety monitoring, protection and fault warning.
• Low internal resistance and flow force circuit design.
• Reinforced insulation design of portable power supply to meet the impact of high voltage surges above 4KV.
• Passed IEC62133, UL, UN38.3 certification.
Longest Lasting Ups Battery Backup
Super Long Life
• The lithium ion UPS battery backup has the same initial performance, consistent charging and discharging dynamics, consistent high and low temperature characteristics, and consistent charging and
discharging curves.
• The lithium ion UPS battery backup has a long calendar life of more than 10 years and a cycle life of 1500 times.
• Intelligent system sleep, low power consumption, strong endurance.
Lower TCO
• Lighter weight,5-6x lighter than VRLA solutions with equivalent energy, providing cost savings and flexibility in shipment, installation & facilities.
• Smaller footprint,it's 40-60% smaller than VRLA, lithium ion UPS battery allows more floor space for revenue-generating equipment.
• Over 65% of the total cost of ownership of the UPS system is reduced by lower maintenance, no battery replacement, and lower operating costs.
Product model table
Model NO. Rated Capacity Operation Voltage Charging Current Max Discharge Current Max Energy Dimension(mm) Weight
Length Width Height
51.2V 118.8Ah LFP 118.8Ah 50.4V 50A 100A 5987.5Wh 400±3mm 630±3mm 130±3mm 65Kg
50.4V 50Ah NCM 50Ah 50.4V 50A 50A 2520Wh 428±1mm 400±1mm 87.5±1mm 8Kg
38.4V 10Ah LFP 10Ah 76.8V 10A 80A 768Wh 310±1mm 207±1mm 66±1mm 8Kg
51.2V 25Ah LFP 25Ah 51.2V 25A 100A 1280Wh 472±1mm 212.4±1mm 117.8±1mm 18Kg
51.2V 100Ah LFP 100Ah 50.4V 50A 100A 5040Wh 520±1mm 436(±1mm 175±1mm 55Kg
38.4V 6Ah LFP UPS Battery 6Ah 38.4V 6A 45A 230.4Wh 470mm 208mm 35mm 5.1Kg
38.4V 5Ah LFP UPS Battery 5Ah 38.4V 5A 60A 192Wh 470mm 208mm 35mm 5.1Kg
12.8V 6Ah LFP UPS Battery (SW version) 6Ah 12.8V 6A 45A 51.2Wh 167mm 208mm 35mm 2.1Kg
12.8V 6Ah LFP UPS Battery(HW version) 6Ah 12.8V 6A 45A 76.8Wh 150mm 65mm 96mm 1.8Kg
25.6V 9Ah LFP UPS Battery 9Ah 25.6V 9A 60A 230.4Wh 183mm 77mm 167mm 3.4Kg
48V 28.8Ah LFP UPS Battery 28.8Ah 48V 28A 50A 1382.4Wh 415~650mm 438mm 86mm 15Kg
48V 12Ah LFP UPS Battery 12Ah 48V 12A 50A 576Wh 415~650mm 438mm 43mm 12Kg
48V 9Ah LFP UPS Battery 9Ah 48V 9A 50A 432Wh 311mm 208mm 67mm 7Kg
48V 6Ah LFP UPS Battery 6Ah 48V 6A 40A 288Wh 183mm 77mm 167mm 4Kg
76.8V 3Ah LFP UPS Battery 3Ah 76.8V 3A 20A 230.4Wh 183mm 77mm 167mm 3.4Kg
76.8V 12Ah LFP UPS Battery 12Ah 76.8V 12A 50A 921.6Wh 570~650mm 438mm 43mm 17.4Kg
76.8V 9Ah LFP UPS Battery 9Ah 76.8V 9A 50A 691.2Wh 462mm 208mm 67mm 11Kg
76.8V 28.8Ah LFP UPS Battery 28.8Ah 76.8V 28A 50A 2211.8Wh 570~650mm 438mm 86mm 35Kg
Application of ithium ion UPS battery backup: The ithium ion UPS battery backup runs with safe and reliable data protection and solves the power supply problems of monitoring, maintenance, and
testing services.
Characteristic of ithium ion UPS system backup: With uninterruptible power supply capability, it can operate normally in grid-connected and off-grid modes, built-in lithium iron phosphate battery,
safe and reliable, long battery life, BMS system charge estimation, environmental monitoring, terminal communication functions, and support high-current charging and discharging.
As one of the most professional ups battery suppliers, we provide china lithium battery, plb battery and etc. If you want to know types of lithium battery cells, please contact us.
