Part number of sightseeing vehicle:
50.4V 60Ah NCM Battery
Features of sightseeing vehicle:
• Power Lithuim-ion battery Pack
• Use in Sightseeing car, golf cart ect
• Packaging with aluminum case
• Long running life, High stability, Low maintenance costs
• Small, Light, Easy to carry, Highly integrated
• IP54 Rating
• Revers polarity protection
• 3D load-bearing structure design,match many kind of application
• RS485 commnication for stable Data-transmission
• Anti-seismic design in any bad condition
• Low-power consumption,Long standby time
• Cover protection & warning design
• RoHS eco-friendly design
• Pack approved by IEC62619/UN38.3 certification
• Head PC to monitor the pack state in accordance customers' need to adjust spec
1.Specification of sightseeing vehicle:
Item Parameter
Model 50.4V 60Ah NCM Battery
Model Capacity 60Ah
Minimum Capacity (0.5C,A) 58.8Ah
Rated Voltage 51.1V
Max Charge Voltage 58.8V
Cut-Off Voltage 39.2V
Standard Charge And Discharge Current 30A
Max Continuous Charge Current 60A
Max Continuous Discharge Current 120A
Weight (Approx. Includes Case) ~23.6Kg
Item Parameter
Impedance (Max, At 1000Hz.) ≤50mΩ
Factory Voltage ≥51.1V
Mode of Communication RS485
Charge Method (CC) 12A(58.8VCut Off)
Charge Method (CV) 58.8V(0.12ACut Off)
Operating Temperature Charging 0℃~45℃
Operating Temperature Discharge -20℃~60℃
Operating Temperature Storage -20℃~45℃
2.Bock diagram of sightseeing vehicle:
Highly intelligent management of battery packs, safe, reliable and stable performance protection design, impedance tracking and ampere-hour estimation, high-precision SOC, charge balance
management, battery data information can be exchanged with PLC through dedicated communication, remote monitoring, online debugging, A dedicated APP monitors the battery status for easy
maintenance.
3.Outline Drawing of sightseeing vehicle:
The SPCC shell design scheme is full of sense of science and technology. The dual-handle design is convenient for installation and transportation. The output interface is dust-proof and foolproof
design to avoid random plugging and short circuit. The three-sided load-bearing three-dimensional design supports multi-sided placement and is suitable for a variety of different models; actual
Size: 581mm*187mm*143mm.
PLB Battery is a professional Lithium Batteries Supplier, we provide china lithium battery, plb battery and etc. If you want to buy lithium battery, please contact us.
