16V 20Ah LFP Medical Equipment Battery

Product Description

Model NO. 16V 20Ah LFP

20Ah 20Ah

16V 16V

10A 10A

10A 10A

320Wh 320Wh

208±1mm 208±1mm

153±1mm 153±1mm

77±1mm 77±1mm

3.9Kg 3.9Kg

Medical Equipment Battery

Part number of medical equipment battery:

16V 20Ah LFP Battery

Features of batteries for medical devices:

• Power Lithuim-ion battery Pack

• Use in Electromedical equipment, mains supply to ensure uninterrupted power

• BMS from imported brand，stable working

• Long running life, High stability, Low maintenance costs

• Head PC to monitor the pack state in accordance customers' need to adjust spec

• Handshake with encrypted protocol

• High capacity density to have a range of long miles on a charge

• High capacity density for longer miles on a charge

• Low-power consumption，Long standby time

• Cover protection & warning design

• RoHS eco-friendly design

• Pack approved by IEC62619/UN38.3 certification

Medical Equipment Battery

1.Specification of battery backup for medical equipment：

Item Parameter

Model 16V 20Ah LFP Battery

Model Capacity 20Ah

Minimum Capacity (0.5C，A) 19.6Ah

Rated Voltage 16V

Max Charge Voltage 18.4V

Cut-Off Voltage 11V

Standard Charge And Discharge Current 4A

Max Continuous Charge Current 10A

Max Continuous Discharge Current 10A

Item Parameter

Weight (Approx. Includes Case) ～3.9Kg

Impedance (Max, At 1000Hz.) ≤50mΩ

The Factory Voltage ≥16V

Mode Of Communication RS485

Charge Method (CC) 4A（18.4VCut Off）

Charge Method (CV) 18.4V（0.4ACut Off）

Operating Temperature Charging 0℃～45℃

Operating Temperature Discharge -20℃～60℃

Operating Temperature Storage -20℃～45℃

2.Bock diagram of medical device energy storage：

Highly intelligent management of battery packs, safe, reliable and stable performance protection design, impedance tracking and ampere-hour estimation, high-precision SOC, charge balance management, battery data information can be exchanged with PLC through dedicated communication, remote monitoring, online debugging, Special APP monitors battery status for easy maintenance.

3.Outline Drawing of medical device energy storage：

SPCC shell solution, beige shell, more suitable for medical equipment, internal shock absorption design, easy to use at any time, special plug, prevent the battery from using the wrong equipment, actual size: 208mm*153mm*77mm, compact and convenient.

PLB Battery is a professional deep cycle battery manufacturer, we provide power long battery, plb battery and etc. If you want to know more, please contact us.
