Characteristics and advantages of LEV Battery
Lev 40 Battery / lev40 battery
Lev Fast Battery Product Features
• Electric bicycles and electric motorcycles are becoming more portable,
environmentally friendly, and low power consumption. The development in the areas of shared electric vehicle,
electric battery swap, and green travel is becoming wider and wider.
Lev batteries are widely used in such light, low-speed powered vehicles.
• Multiple safety management strategies of lithium battery for electric vehicle: overcharge/overdischarge
/overcurrent/overtemperature/short circuit protection.
• The battery housing of e mobility battery adopts a tight ultrasonic seal craft,
which meets the IP54 requirements of the product or more.
• Dedicated lithium ion vehicle battery output interface design, stable and reliable.
Lev Fast Battery Price
Safe And Reliable
• Imported special IC and MOSFET for lithium vehicle battery are used to ensure the safe use and stable performance of the vehicle battery.
• Use lev fast battery that meets the requirements of vehicle regulations.
• Passed IEC62133, UL, UN38.3 certification.
Lev 40 Battery
Super Long Life
• The initial performance of the lev battery is consistent, the charging and discharging dynamics are consistent, the attenuation trend is consistent, and the self-consumption is consistent.
• The cycle life of the e mobility battery product that Powerlong electric vehicle lithium ion battery manufacturer provides can reach more than 4000 times.
• Low power consumption and high energy density lev fast battery design, with longer battery life.
Product model of LEV Battery
25.2V 10Ah NCM Battery
25.2V 10Ah NCM Electric Wheelchair Battery
Model NO.25.2V 10Ah NCM
Specification
Nominal Capacity: 10Ah
Operating Voltage: 21~29V
Charging current: ≤5A
Discharging current: ≤15A
Temperature: -20~60℃
Dimension: 194*146*30mm(±1mm)
Weight: 2Kg
Packaging: Plastic case
Protection: PCM(Customized available)
50.4V 60Ah NCM Battery
50.4V 60Ah NCM Electric Sightseeing Car Battery
Model NO.50.4V 60Ah NCM
Specification
Nominal Capacity: 60Ah
Operating Voltage: 39.2~58.8V
Charging current: ≤60A
Discharging current: ≤120A
Temperature: -20~60℃
Dimension: 578*187*143mm(±1mm)
Weight: 23.6Kg
Packaging: SPCC Aluminum case
Protection: BMS(Customized available)
50.4V 30Ah NCM Electric Motorcycle Battery
50.4V 30Ah NCM Electric Motorcycle Battery
Model NO.50.4V 30Ah NCM
Specification
Nominal Capacity: 30Ah
Operating Voltage: 39.2~58.8V
Charging current: ≤30A
Discharging current: ≤30A
Temperature: -20~60℃
Dimension: 220*180*315mm(±1mm)
Weight: 11Kg
Packaging: SPCC Plastic Case
Protection: PCM(Customized available)
50.4V 10Ah NCM Electric Bicycle Battery
50.4V 10Ah NCM Electric Bicycle Battery
Model NO.50.4V 10Ah NCM
Specification
Nominal Capacity: 15Ah
Operating Voltage: 39.2~58.8V
Charging current: ≤10A
Discharging current: ≤20A
Temperature: -20~60℃
Dimension: 367.5*190*90.3mm(±1mm)
Weight: 5.5Kg
Packaging: Plastic case
Protection: PCM(Customized available)
25.6V 10Ah LFP Robotic Vacuum Battery
25.6V 10Ah LFP Intelligent Cleaning Robot Battery
Model NO.25.6V 10Ah LFP
Specification
Nominal Capacity: 10Ah
Operating Voltage: 17.6~29V
Charging current: ≤5A
Discharging current: ≤10A
Temperature: -20~60℃
Dimension: 227*97*68mm(±3m)
Weight: 25Kg
Packaging: PVC
Protection: PCM(Customized available)
51.2V 33Ah LFP Battery
51.2V 33Ah LFP AGV Battery
Model NO.51.2V 33Ah LFP
Specification
Nominal Capacity: 33Ah
Operating Voltage: 40~58V
Charging current: ≤30A
Discharging current: ≤30A
Temperature: -20~60℃
Dimension: 320*250*170mm(±1m)
Weight: 20Kg
Packaging: SPCC Plastic Case
Protection: PCM/BMS(Customized available)
16V 20Ah LFP Medical Equipment Battery
16V 20Ah LFP Medical Equipment Battery
Model NO.16V 20Ah LFP
Specification
Nominal Capacity: 20Ah
Operating Voltage: 11~19.6V
Charging current: ≤10A
Discharging current: ≤10A
Temperature: -20~60℃
Dimension: 208*153*77mm(±1m)
Weight: 3.9Kg
Packaging: SPCC Plastic Case
Protection: BMS(Customized available)
Product model table
Model NO. Rated Capacity Operation Voltage Charging Current Max Discharge Current Max Energy Dimension(mm) Weight
Length Width Height
25.2V 10Ah NCM 10Ah 25.2V 5A 15A 252Wh 194±1mm 146±1mm 30±1mm 2Kg
50.4V 60Ah NCM 60Ah 51.1V 60A 120A 3066Wh 578±1mm 187±1mm 143±1mm 23.6Kg
50.4V 30Ah NCM 30Ah 50.4V 30A 30A 1512Wh 220±1mm 180±1mm 315±1mm 11Kg
50.4V 10Ah NCM 10Ah 50.4V 15A 20A 504Wh 367.5±1mm 190±1mm 90.3±1mm 4.5Kg
25.6V 10Ah LFP 10Ah 25.6V 5A 10A 256Wh 227±3mm 97±3mm 68±3mm 2.5Kg
51.2V 33Ah LFP 33Ah 51.2V 30A 30A 1689.6Wh 320±1mm 250±1mm 170±1mm 20Kg
16V 20Ah LFP 20Ah 16V 10A 10A 320Wh 208±1mm 153±1mm 77±1mm 3.9Kg
Application Of Lev Fast Battery
Lithium ion vehicle battery is widely used for power support in electric wheelchairs, electric sightseeing cars, electric motorcycles, electric bicycles and other fields.
Characteristic Of E Mobility Battery
The lev battery is light in weight, small in size, adaptable, easy to install and disassemble, high energy density, strong power, strong endurance, supporting fast charging and quick release,
sturdy and durable external structure, waterproof and dustproof, low self-discharge rate, and service life long.
PLB Battery is a professional lithium battery manufacturer, we provide power long battery, industrial batteries for sale and etc. If you want to know more, please contact us.
