LiFePO4 Lithium Battery Cells

Characteristics and advantages of LiFePO4 Lithium Battery Cells

Lifepo Lithium Battery

High Energy Density, High Consistency

• LFP power cell energy density of weight is 145wh/kg.

• LFP cell energy density of volume is 370wh/L.

• Industry leader in terms of lifepo4 battery cell voltage for sale energy density.

• High static initial voltage consistency, matching capacity 1%, voltage 2mV, internal resistance 2mΩ.

• Dynamic voltage difference is consistent. The charge-discharge cut-off voltage of lifepo battery cells is highly consistent.

• High consistency on attenuation trend. After a long cycle, the parameters of lifepo4 battery cells for sale are highly consistent.

Lifepo4 Battery Cells For Sale

Long Cycle Life

• The lithium iron phosphate high power battery cell cycles more than 8000 times.

• Power-type lithium iron phosphate batteries cycle more than 6000 times.

• Energy type Lithium iron Phosphate batteries can run more than 4000 cycles.

• Calendar life of lifepo batteries for sale is over 12 years.

Lifepo4 Cylindrical Cells

High Security

• NO explosions, NO fires, and NO liquid leakage accidents over 200 million shipped cells.

• In-depth research on the basic principles of battery cell thermal runaway, high-safety separator selection, and automatically cut off the current under high temperature conditions.

• High safety structure design, precise pressure relief device.

• During the lfp battery cell manufacturing process, burrs and magnetic metal impurities are strictly controlled.

Strong Environmental Adaptability

• Discharge temperature range of lifepo4 battery cells: -40~85℃.

• Charging temperature range of lifepo4 cells / lifepo4 cells for sale: -20~60℃.

• Lifepo battery cells are widely used in various heat and cold areas in the world.

Product model of LiFePO4 Lithium Battery Cells

LFP Cell(Rate) IFR26650-2500mAh

LFP Cell(Rate) IFR26650-2500mAh

Model NO.IFR26650-2500mAh(Rate)

Capacity: ≥ 2500mAh

Impendance: ≤ 6mΩ

Voltage: 3.2V

Diameter: 26.3 ± 0.2mm

Height: 65.2 ± 0.3mm

LFP CELL IFR26650-3000mAh

LFP Cell(Rate) IFR26650-3000mAh

Model NO.IFR26650-3000mAh(Rate)

Capacity: ≥ 3000mAh

Impendance: ≤ 10mΩ

Voltage: 3.2V

Diameter: 26.3 ± 0.2mm

Height: 65.3 ± 0.3mm

IFR 26650 Cell, Cell 26650

LFP Cell IFR26650-3300mAh

Model NO.IFR26650-3300mAh

Capacity: ≥ 3300mAh

Impendance: ≤20mΩ

Voltage: 3.2V

Diameter: 26.3 ± 0.2mm

Height: 65.3 ± 0.3mm

LFP CELL IFR26650-3400mAh

LFP Cell IFR26650-3400mAh

Model NO.IFR26650-3400mAh

Capacity: ≥ 3400mAh

Impendance: ≤ 20mΩ

Voltage: 3.2V

Diameter: 26.3 ± 0.2mm

Height: 65.3 ± 0.3mm

LFP CELL IFR26650-3600mAh

LFP Cell IFR26650-3600mAh

Model NO.IFR26650-3600mAh

Capacity: ≥ 3600mAh

Impendance: ≤ 20mΩ

Voltage: 3.2V

Diameter: 26.3 ± 0.2mm

Height: 65.6 ± 0.3mm

LFP 26650 Lithium Ion Battery

LFP Cell IFR26650-3800mAh

Model NO.IFR26650-3800mAh

Capacity: ≥ 3800mAh

Impendance: ≤ 20mΩ

Voltage: 3.2V

Diameter: 26.3 ± 0.2mm

Height: 65.3 ± 0.3mm

Product model table

Model NO. Nominal Voltage Rated Capacity Internal Resistance Discharge Rate Dimensions Weight

Diameter Height

IFR26650-3800mAh 3.2V 3800mAh ≤20mΩ 1.3C 26.3±0.2mm 65.3±0.3mm 88g

IFR26650-3600mAh 3.2V 3600mAh ≤20mΩ 3C 26.3±0.2mm 65.6±0.3mm 85g

IFR26650-3300mAh 3.2V 3300mAh ≤20mΩ 3C 26.3±0.2mm 65.3±0.3mm 88g

IFR26650-3400mAh 3.2V 3400mAh ≤20mΩ 3C 26.3±0.2mm 65.3±0.3mm 85g

IFR26650-3000mAh(Rate) 3.2V 3000mAh ≤10mΩ 10C 26.3±0.2mm 65.3±0.3mm 85g

IFR26650-2500mAh(Rate) 3.2V 2500mAh ≤6mΩ 30C 26.3±0.2mm 65.2±0.3mm 86g

Lifepo4 battery cells have energy type, power type and high rate type, are suitable for lead-acid replacement, photovoltaic energy storage, residential energy storage, portable power supply, light vehicles, UPS of data center and other occasions.

LFP Battery VS Lithium Ion

Lifepo4 cylindrical cells generally refer to a secondary battery (rechargeable battery) that rely on lithium ions between the positive electrode and the negative electrode. During the charge and discharge process of lifepo4 cylindrical cells, Li + is built and deodded between two electrodes; lfp battery cells / lfp battery cell are specifically referred to lithium ion batteries in lithium iron phosphate as a positive material, except for lithium iron phosphate batteries, the lifepo lithium battery also includes a lithium cobalt organte, a ternary battery, etc. In contrast, the lifepo cell / lfp cylindrical cells energy density is slightly lower than the lithium cobaltate battery and the ternary battery, but has longer life, higher safety, no pollution, and low price, currently widely used in the new energy vehicle applications.

Lifepo4 cell voltage chart

Including charging maps and discharge maps, charging is charged with the given current to the battery, the lifepo4 cell voltage gradually increases as time goes by, after the upper limit voltage is reached, the charging is completed; the time or the charging capacity is an X-axis, voltage change value The chart made for the Y-axis is charging. The discharge is discharged by the given current, and the voltage gradually decreases as time goes by. After the lower limit voltage is reached, the discharge is completed; with the time or discharge capacity of the X-axis, the chart of the lfp cell voltage change value is the Y-axis is Discharge. In addition, during the process of charging and discharging of lifepo lithium battery, voltage variation is very gentle, which means a relatively stable discharge platform.

PLB Battery is a professional lithium battery supplier and lfp battery manufacturer, we provide power long battery, industrial batteries for sale, lifepo 26650 and etc. If you want to know more, please contact us.
