Centrifuge

Place Of Origin: Beijing

Minimum Order: 1

Packaging: N/A

Delivery: 3 to 6 months

HVD-TCF-P is an automated upper suspension centrifuge device with mechanical unloading. All parts contact with the material and water, steam pipeline is made of stainless steel or corrosion resistant materials, to ensure the cleanliness of the separated products. Using pneumatic mechanical scraper discharge, centrifuge instrument makes unloading safe and reliable and suitable for separating suspension containing medium and fine particles crystal. If you want to buy commercial centrifuge, Hongvadar is the best choice for you as one of the qualified centrifuge companies.

Centrifuge Application

HVD-TCF-P automated upper suspension centrifuge is mainly used for centrifuge dewatering of a saccharide in sugar industry, but also for the separation of solid and liquid of the B saccharide, grape saccharide or similar crystal materials with high viscosity and high concentration. Centrifugation in food processing is really common.

Centrifuge Main Advantages

Automatic control to ensure the separation effect;

Stepless speed regulation;

Wide speed range;

Large starting and braking torque;

Good low speed centrifuge capacity;

Centrifuge Technical Parameters

Model HVD-TCF1400-P90 HVD-TCF1600-P110

Drum inner dia. mm φ1348 φ1600

Max. drum rotary speed, rpm 1410 1100

Max. separation factor 1500 1083

Drum effective volume, L 778 1089

Max. material loading qty. kg 1300 1750

Power, kW 90 110

Overall dimension, mm 2420×1910×4820 2240×2160×5100

Weight, kg 9000 9500

Beijing Hongvadar Engineering Technology Co. Is a professional hydrocyclone manufacturers, we provide corn starch production plant, continuous crystallization equipment, automated centrifuge and etc. For more info or buy centrifuge, contact us.
