Ring / Cylinder Forging Component
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Ring forgings are ring-shaped objects in which external force is applied against the metal blank and transform it by plastic deformation. This force is typically achieved through the use of hammer
or pressure. The forging process creates a fine grain structure and improves the physical properties of the metal. Ring forgings can be seen everywhere in daily life.
Cylindrical parts are an important type in the custom forgings and are important component of products such as pressure vessels and cracking reactors. The forged steel round bar can be produced
according to the drawings and requirements provided by the customer. The surface of the forgings is clean and has small machining allowance.
Ring / Cylinder Forgings Main parameters
Ring: Outside diameter≤Φ850mm Cylinder：Outside diameter≤Φ850mm
Ring / Cylinder Forgings Common Technical Standards
Ring: NB/T47008~47010
Cylinder: GB/T3077 EN10083 EN10085 JB/T6395
Ring / Cylinder Forgings Typical Steel Grades
Ring: #20, #35, 16Mn, 15CrMo, 1.25Cr-0.5Mo, 2.25Cr-1Mo, 2.25Cr-1Mo-0.3V, 12Cr2Mo1V, 21CrMo10, 0-1Cr8Ni9(Ti), 1Cr17Ni2, 304(L),316L(N), 321, 347, 00Cr19Ni13Mo3, 00Cr22Ni5Mo3N
Cylinder: 18CrNiMo7-6, 17CrNiMo6, 20CrNiMo, 20CrNi2Mo, 20CrMnMo, 20CrMnTi, 34CrNiMo6, 30CrNiMo8, 40CrNiMo, 35CrMo, 42CrMo
Ring / Cylinder Forgings Applications
Like our disk forging products, the ring/cylinder forgings can be used for gears, wheels, etc. for port machinery and marine machinery. Pressure vessel forgings for chemical machinery
As a die steel supplier, we can offer kinds of hot work steel for sale, anything you need, please leave us a message.
