SUNSHINE 3.5/5.5KW Off Grid Inverter
Product Quick Detail
- FOB Price
- USD $40.00 / Piece
- Place Of Origin
- China
- Minimum Order
- 100
- Packaging
- N/A
- Delivery
- 30 days
Specifications
SUNSHINE is an off-grid inverter from Microtek with MPPT function, which can convert solar energy to the maximum extent; with RGB lighting, it has a gorgeous appearance and has three lighting
modes. Its Rated Power is 3.5/5.5KW, suitable for small home, RV or outdoor.
Features of SUNSHINE 3.5/5.5KW Off Grid Solar Inverter
RGB Light.
PV input.
WIFI Monitor.
Communication：RS232, USB, RS485, WIFI.
Specifications Of SUNSHINE 3.5/5.5KW Off Grid Inverter
MODEL SUNSHINE 3.5KW SUNSHINE 5.5KW
Rated Power 3500VA/3500W 5500VA/5500W
BATTERY
Battery Voltage 24VDC 48VDC
Floating Charge Voltage 27VDC 54VDC
Overcharge Protection 33VDC 63VDC
INPUT
Voltage 230VAC 230VAC
Selectable Voltage Range 170-280VAC(For Personal Computers); 90-280VAC(For Home Appliances) 170-280VAC(For Personal Computers); 90-280VAC(For Home Appliances)
Frequency Range 50Hz/60Hz(Auto sensing) 50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation(Batt. Mode) 230VAC±5% 230VAC±5%
Surge Power 7200VA 11200VA
Effciency(Peak) 90%~93% 90%~93%
Transfer Time 15ms(For Personal Computers); 20ms(For Home Appliances) 15ms(For Personal Computers); 20ms(For Home Appliances)
Waveform Pure sine wave Pure sine wave
SOLAR CHARGER&AC CHARGER
Solar Charger Type MPPT MPPT
Maximum PV Array Power 4000W 6000W
MPPT Range@Operating Voltage 120~450VDC 120~450VDC
Maximum PV Array Open Circuit Voltage 500VDC 500VDC
Max mum Solar Charge Current 120A 120A
Maximum AC Charge Current 100A 100A
Maximum Charge Current 120A 120A
PHYSICAL
Dimension, D x W x H(mm) 115x300x400 552x422x152mm
Net Weight(kgs) 9 18
Communication Interface USB/RS232/RS485(BMS) /Local WiFi/Dry-contact USB/RS232/RS485(BMS) /Local WiFi/Dry-contact
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing) 5%to 95% Relative Humidity(Non-condensing)
Operating Temperature -10°C to 50°C -10°C to 50°C
Storage Temperature -15°C to 60°C -15°C to 60°C
Benefits Of Solar Inverter SUNSHINE 3.5/5.5KW
Brilliant RGB lighting.
High Efficiency Solar PV Input.
WiFi monitoring, can be operated by mobile phone.
Can be used with or without battery.
Touch LCD screen buttons for intuitive, clear image and space saving.
How To Use Ｍicrotek Solar Inverter SUNSHINE 3.5/5.5KW?
The output power of the SUNSHINE 3.5KW off grid sunshine solar inverter must be greater than the total power of the electrical appliances used at the same time, the DC voltage must be consistent
with the battery voltage, and the positive and negative poles must be connected correctly.
The inverter must be placed in a well-ventilated, non-humid place to avoid rain. It should be at least 10 cm away from surrounding objects. The last startup should not be too frequent, and the time
interval between two startups should be more than 5 seconds.
Solar Inverter SUNSHINE 3.5/5.5KW FAQs
What is the voltage of SUNSHINE 3.5/5.5kw?
Battery voltage is 24VDC, input/output voltage is 230VAC.
