The SUNNY series product is an off-grid solar inverter with a parallel function. The stable and good parallel operation of the inverter will greatly improve the reliability and capacity of the
micro grid system. This model can be connected in parallel with a maximum of 6 inverters.
Features of SUNNY 5KW Off Grid Solar Inverter
With High PV Input Voltage Range(120-500VDC).
With WIFI Function Optional.
With Touch Button on the LCD Display.
Efficently work with or without battery.
With 100A MPPT Solar Charge Controller Built-in.
Max. Can Be 6PCS in Parallel.
Specifications Of SUNNY 5KW Off Grid Inverter
MODEL SUNNY 5KW
The rated power 5000VA/5000W
INPUT
Voltage 208/220/230/240VAC
Selectable Voltage Range 185-264VAC±3V(UPS); 154-264VAC±3V(Appliances)
Frequency Range 50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation(Batt. Mode) 208/220/230/240VAC±5%
Surge Power 10000VA
Effciency(Peak) >94%
Transfer Time 10ms(UPS); 20ms(Appliances)
Wave form Pure sine wave
No Load Current 1.3A
BATTERY
Battery voltage 48VDC
Constant charging voltage(adjustable) 56.4VDC
Low battery cut off protection voltage 42VDC
Low battery recovery voltage 46.0VDC
Floating Charge Voltage 54VDC
Overcharge Protection 64VDC
MPPT SOLAR CHARGER&AC CHARGER
Maximum PV Array Power 5500W
MPPT Range at Operation Vol. 120~430VDC
Maximum PV Array Open Circuit Vol. 500VDC
Number of MPPT trackers/Max output current 100A
Maximum AC Charge Current 100A
Max mum Charge Current 100A
Max mum Efficiency 98%
DISPLAY
LCD Operating mode/load/input/output
PHYSICAL
Products Dimension, WxDxH(mm) 312x495x125
Packing size, WxDxH(mm) 395x577x217
Net Weight(kgs) 13KG
G.W.kg 14.5KG
OPERATING ENVIRONMENT
Operating Environment 20%~95%(Non condensing)
Operation Temperature 0℃-50℃
Benefits Of Solar Inverter SUNNY 5KW
High power transmission efficiency.
Can support WiFi function.
LCD display, fast button response, safe and reliable.
Works efficiently with or without the battery.
Up to 6PCS can be connected in parallel.
How To Use Microtek Best Inverter SUNNY 5KW?
The main function of SUNNY 5KW photovoltaic inverter is to convert the direct current generated by solar panels into alternating current used by home appliances. Before making the electrical
connection of the PV inverter, make sure that the DC switch of the inverter is in the "OFF" state, and disconnect the AC side circuit breaker. Then there is each inverter to be installed
independently - an AC circuit breaker.
It is forbidden to connect the load between the inverter and the circuit breaker. It is forbidden to use single-core wire at the inverter output. It should be noted that the protective ground wire
PE needs to be connected, and it is also necessary to ensure that the output wire is well connected before turning on the inverter.
Solar Inverter SUNNY 5KW FAQs
How many solar panels can SUNNY 5KW match?
Best panel configuration: 300Wp*6pcs*30V(2700Wp) * 2 Parallel.
Can SUNNY 5KW load air conditioners?
Yes, but you cannot use appliances that exceed the total limit at the same time.
Can SUNNY 5KW store electric energy?
Of course, SUNNY 5KW is an off grid inverter, which converts solar energy into electrical energy in the photovoltaic system and stores it in the battery.
