SUNSHINE 8KW Off Grid Solar Inverter
Product Quick Detail
- FOB Price
- USD $40.00 / Piece
- Place Of Origin
- China
- Minimum Order
- 100
- Packaging
- N/A
- Delivery
- 30 days
Specifications
SUNSHINE 8KW has two power models, which can meet the needs of most medium and large power equipment. Photovoltaic input, no need to connect to the grid, eliminating the trouble of power failure.
Touchable LCD panel design for easy operation.
Features of SUNSHINE 8KW Off Grid Solar Inverter
1. Touch Button and LCD.
2. Work with or without battery.
3. USB On-the-go Function.
4. Reserved communication port for BMS.
5. 120A Solar Charger+AC Charging current.
Specifications Of SUNSHINE 8KW Off Grid Solar Inverter
MODEL SUNSHINE 8KW
Rated Power 8000VA/8000W
BATTERY
Battery Voltage 48VDC
Floating Charge Voltage 54VDC
Overcharge Protection 66VDC
INPUT
Voltage 230VAC
Selectable Voltage Range 170-280VAC(For Personal Computers); 90-280VAC(For Home Appliances)
Frequency Range 50Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation(Batt. Mode) 230VAC±5%
Surge Power 16000VA
Effciency(Peak) 90%~93%
Transfer Time 15ms(For Personal Computers); 20ms(For Home Appliances)
Wave form Pure sine wave
SOLAR CHARGER&AC CHARGER
Solar Charger Type MPPT
Maximum PV Array Power 8000W
MPPT Range@Operating Voltage 120~450VDC
Maximum PV Array Open Circuit Voltage 500VDC
Max mum Solar Charge Current 150A
Maximum AC Charge Current 120A
Maximum Charge Current 150A
PHYSICAL
Dimension,D x W x H(mm) 552x422x152mm
Net Weight(kgs) 18.5
Communication Interface USB/RS232/RS485(BMS) /Local WiFi/Dry-contact
OPERATING ENVIRONMENT
Humidity 5%to 95% Relative Humidity(Non-condensing)
Operating Temperature -10°C to 50°C
Storage Temperature -15°C to 60°C
Benefits Of Solar Inverter SUNSHINE 8KW
RGB lighting, cool and colorful.
Photovoltaic input, abundant resources, clean and pollution-free.
WiFi monitoring is very convenient to install and use.
BMS reserved communication port with strong scalability.
USB OTG enhancement function, increase host function, point-to-point communication.
How To Use Microtek Solar Inverter SUNSHINE 8KW?
When using SUNSHINE 8KW off grid solar inverter, it is necessary to pay attention to the rated output capacity of the inverter not to overload; secondly, the output voltage should have good
stability and match the battery voltage; thirdly, pay attention to the efficiency of the inverter to maximize the power generation; The operator should pay attention to the over-voltage,
over-current and short-circuit protection functions of the inverter, and maintain it in time; finally, ensure that the inverter is started under the rated load.
Solar Inverter SUNSHINE 8KW FAQs
How to charge the battery of SUNSHINE 8KW?
SUNSHINE 8KW is an off-grid solar inverter that charges the battery by harvesting solar energy.
