Smart T Plus Rental Hanging LED Screen

Smart T Plus Rental Hanging LED Screen

ONUMEN Smart T Plus series mesh foldable hanging LED

Waterproof led display, waterproof led screens for outdoor use

ONUMEN Smart T Plus series mesh foldable led screen for outdoor use.

Mesh design with great simplicity and transparency, blocking no view from interior.

Waterproof outdoor led display screen

Smart T Plus Rental Hanging LED Screen Highlights

Module size: 250mm * 375mm

360° foldable

High brightness and IP65 rating with waterproof grout for outdoor use

Slim and light, mesh design, weatherproof

Detachable design for easy installation

Optional motor for one-touch lifting, lowering and folding.

Details of Smart T Plus Rental Hanging Portable LED Display

Screen

Application Environment Outdoor

Model Smart T plus 7 Smart T plus 10 Smart T plus 15 Smart T plus 37

Pixel Pitch (mm) 7.8 10.4 15.6 37.5

IP Rating IP65 IP65 IP65 IP65

Transparent rate 12% 12% 14% 56%

LED Type SMD 1921 SMD 2727 SMD 2727 SMD 2727

Pixel Density (pixel/㎡) 16384 9216 4096 4000

Driving Mode 1/4 1/4 1/2 静态

Gray Scale (bit) 16 16 16 16

Max Brightness (nits) 6000 6000 5000 6000

Max Refresh Rate (Hz) 7680 8000 8000 64000

Module Resolution (pixels) 32 * 48 24 * 32 16 * 24 15 * 12

Module Size (mm) 250 * 250 250 * 250 250 * 375 300*450

Screen Thickness (mm) 16.5 16.5 16.5 16.5

Weight (kg/㎡) 12 12 12 12

Folding Angle 360° 360° 360° 360°

Viewing Angle (H/V) 120° / 120° 120° / 120° 120° / 160° 120° / 160°

Max Power Consumption (w/㎡) 400 560 450 370

Output Voltage (V) DC24/48 DC24/48 DC24/48 DC24/48

Input Voltage (V) AC100 ~ AC240 AC100 ~ AC240 AC100 ~ AC240 AC100 ~ AC240

Max Height of a Panel (m) 12 16 24 24

Best Viewing Distance (m) ≥8 ≥10 ≥15 ≥37.5

Brightness adjustment (levels) (digital) 256 256 256 256

Brightness adjustment (levels) (analog current) (option) 64-256 64-256 64-256 64-256

Contrast 2500:01:00 2500:01:00 2500:01:00 2500:01:00

Connection Type (standard) (spare) 2+14pin Soldering 50pin Connector 2+14pin Soldering 50pin Connector 2+14pin Soldering 50pin Connector 2+14pin Soldering 50pin Connector

Short Circuit Protection Yes Yes Yes Yes

Quick Maintenance Yes Yes Yes Yes

Controlling Mode synchronous asynchronous synchronous asynchronous synchronous asynchronous synchronous asynchronous

Installation Method Hanging dance floor led display Hanging dance floor led display Hanging dance floor led display Hanging

Magnet mounting Magnet mounting Magnet mounting dance floor led display

Magnet mounting

Operation temperature (℃) -40 ~ 65 -40 ~ 65 -40 ~ 65 -40 ~ 65

Operation humidity (RH) 0% ~ 90% 0% ~ 90% 0% ~ 90% 0% ~ 90%

Certificate ROHS FCC TUV CE
